4
SERVICE INFORMATION HCR-1500
1-3 Torque limits
* Apply thread locking sealant. (See below.)
† Tapping screw.
NOTE: Adjusting cutter clearance
Fasten all cutter bolts to this torque, then back 1/2 turns(180°) counterclockwise.
Material Location Remarks
Grease Gear case
Rewind spring Lithium based grease
Starter center post
Thread locking sealant Starter case
Carburetor insulators
Fuel tank Loctite #222, ThreeBond #1342, or equivalent
Gear case
Rear handle to handle fixture
1-4 Special repairing materials
Descriptions Size kgf•cm in•lbf
Starter Pawl carrier M 8 160 - 200 140 - 175
system Starter case M 4 * 14 - 28 12 - 24
Ignition Ignition coil (CDI module) M 4 35 - 50 30 - 45
system Spark plug M14 130 - 170 110 - 150
Fuel Carburetor insulator M 5 * 25 - 40 22 - 35
system Carburetor M 5 25 - 40 22 - 35
Throttle cable nut M 6 25 - 35 22 - 30
Fuel tank M 5 * 25 - 40 22 - 35
Clutch Clutch hub M 8 160 - 200 140 - 175
Engine Crankcase M 5 70 - 110 60 - 95
Cylinder M 5 70 - 110 60 - 95
Muffler M 5 60 - 100 52 - 85
Gear Gear case M 4 * 30 - 50 26 - 45
case with cylinder cover M 4 * 14 - 28 12 - 24
Bottom cover M 4 35 - 50 30 - 45
Cutter Cutter bolts (See NOTE below) M 6 10 - 15 9 - 13
Cutter nuts M 6 50 - 60 45 - 52
Handle Rear handle set M 5 † 10 - 20 9 - 18
Rear handle set to handle fixture M 5 * 25 - 40 22 - 35
Handle fixture to gear case M 5 25 - 30 22 - 26
Regular bolt, nut, and screw M 3 6 - 10 5 - 9
M 4 15 - 25 13 - 22
M 5 25 - 45 22 - 40
M 6 45 - 75 40 - 65
M 8 110 - 150 95 - 130
M10 210 - 300 180 - 270
