1 SERVICE INFORMATION
1-1 Specifications
* See NOTE on page 4.
Dimensions Length mm(in) 1022 (40.2)
Width mm(in) 237 ( 9.3)
Height mm(in) 197 ( 7.8)
Dry weight kg(lb) 5.0 (11.0)
Engine Type KIORITZ, air-cooled, two-stroke, single cylinder
Rotation Counterclockwise as viewed from the output end
Displacement cm 3 (in 3 ) 21.2 (1.294)
Bore mm(in) 32.2 (1.268)
Stroke mm(in) 26.0 (1.024)
Compression ratio 6.6
Carburetor Type Diaphragm, horizontal-draught, with primer (purge pump)
Model ZAMA C1U-K51
Ignition Type CDI (Capacitor discharge ignition) system
in a single integrated piece
Spark plug BPM7Y, RCJ-8Y
Starter Type Automatic rewind
Rope diameter x length mm(in) 3.0 x 890 (0.12 x 35.0)
Fuel Type Premixed two-stroke fuel (Refer to Operator's manual.)
Tank capacity cm 3 (U.S.fl.oz.) 300 (14.2)
Clutch Type Centrifugal, 2-shoe slide
Handle Type Front Rubber grip
Rear Rubber grip with throttle trigger
Gear case
Reduction ratio 5.88
Gear tooth Spiral bevel
Lubrication Lithium based grease
Cutter
Type Double reciprocating, double edge blade
Length mm(in) 550 (21.7)
Pitch mm(in) 35 ( 1.4)
Height mm(in) 21 ( 8.3)
Thickness mm(in) 2.5 (0.098)
Clearance* mm(in) 0.25 - 0.5 (0.01 - 0.02)
Lubrication Apply oil every 4 hours of use
2
SERVICE INFORMATION HCR-1500
