Page 7: Dimensions 4, Installation type 3
www.stiebel-eltron.com
7
installation manual
psH 30 - 200 tm
www.stiebel-eltron.com
www.stiebel-eltron.com
Theappliancemustbeconnectedtothepowersupplytakingthe
applicableinstallationinstructionsandtherelevantstandardsandre-
gulationsintoconsideration.Itisparticularlyimportanttoobservethe
“Regulationsforinstallinghigh-voltagesystemswithratedvoltagesup
to1000V”andregulationsfromthelocalpowersupplycompany.The
appliancesareonlydesignedforpermanentconnectiontoa230V~
ACnetwork.Forthis,installanisolatorthatdisconnectsallpolesofthe
powercablewithatleast3mmcontactseparation(e.g.fuse).
!
Electrical connection should be carried out by an authorised
fitter only.
Whendelivered,thePSH30...200wall-mountedstorageheatersare
wiredinthewayshownincircuitdiagram
2
.
Initial Start-up
Thespecialisttechnicianmustmonitortheappliancewhenitisputinto
operationandheatswaterforthefirsttime.
Maintenance
Theoutsideofthestorageheaterdoesnotrequireanyspecialmainte-
nance.Toclean,wipeusingasoftclothordampspongeonly.Donot
useanyabrasiveagentsoraggressivedetergents.
!
Caution! Always fully disconnect the appliance from the power
supply before carrying out any maintenance work.
Technical specifications
Type
PSH
30TM
50TM
80TM
100TM
120TM
150TM
200TM
Ratedvoltage
1/N/PE~230V
powerconsumption
W
2000
2000
2000
2000
2000
2000
2000
Nominalcapacity
Liter
30
50
80
100
120
150
200
Powerconsumptioninstand-by
mode
kWh/d
0,73
0,93
1,16
1,48
1,71
2,01
2,90
Drawablequantityofmixed
water
at40°C
(1)
Liter
56,2
101,5
144,3
186
227,9
291
385,3
Weight(empty)
kg
16
21
26
30
34
41
50
Weight(wet)
kg
46
71
106
130
154
191
250
Dimensions
A
mm
100
100
100
100
100
100
100
B
mm
296
296
274
274
274
274
274
C
mm
47
47
28
28
28
28
28
D
mm
390
390
470
470
470
470
470
E
mm
530
591
583
735
889
1125
1425
H
mm
585
840
810
962
1116
1352
1652
I
mm
102
296
255
255
255
255
255
K
mm
386
386
485
485
485
485
485
M
mm
78
78
75
75
75
75
75
X
mm
G1/2“
G1/2“
G3/4“
G3/4“
G3/4“
G3/4“
G3/4“
Permissibleoperatingpressure
MPa
0,6
Degreeofprotection
Protectionagainstwaterjets(IP25)
Markofconformity
Seeratingplate
(1)
Cold water inlet 15 °C and cylinder temperature 65 °C
Toensurealongservicelife,itisrecommendedtohaveaspecialist
technicianinspecttheanti-corrosionanode(magnesiumanode)inthe
applianceonceperyear.Thischeckmayneedtobecarriedoutmore
frequentlyinareaswithparticularlyaggressivewater–askthefitteror
yourlocalwatersupplycompanyforinformation.
Theapplianceisprotectedagainstoverheatingbyasafetytemperature
limiterwhichinterruptsallphases.Ifthesafetytemperaturelimiterhas
beentriggered,anauthorisedspecialisttechnicianisrequiredtocarry
outtherepairwork.Thehighlimitsafetycut-outcanberesetbypres-
singthepushbutton(markedSafety)onthecontrollerbelowthecontrol
panelcover.
Dimensions
4
Dimensionsofstorageheater(seetable“Technicalspecifications”)
1 Heatingflange
2 Magnesiumanode
3 Deliverypipe
4 Temperatureselectionknob
5 Mountingbracket
6 Signallamp
Installation type
3
1 Safetyvalve
2 Non-returnvalve
3 Pressuretestconnection
4 Stopvalve
5 Pressurereducer
6 Drawingpoints
7 Drainoutlet/siphon
