10
ASW 12 EN
Operating instructions for the cordless
torque wrench.
Overview.
1 Cover
For covering the torque adjustment.
2 Cap
Remove cap and adjust the torque.
3 Torque adjustment
For setting the torque.
4 LED display
For indicating the operating modes,
Green lamp (a),
Red lamp (b).
5 Switch
For switching ON/OFF.
6 Switch for reverse rotation
Select when power tool is at a stand-
still.
7 Illumination
For illuminating the screw position.
8 Tool holder
Mount the tool.
9 Battery
Remove the battery from the power
tool and charge using the battery
charger.
10 Supplied accessories
Setting key Ø 4 mm (c).
For your safety.
Before using this power tool,
read and comply with:
these operating instructions and the
operating instructions for the respective
battery charger and batteries,
the enclosed safety instructions
(document number 3 41 30 054 06 1),
the relevant national industrial safety
regulations.
These operating instructions and the
enclosed safety information should be
kept carefully for later use and enclosed
with the power tool, should it be passed
on or sold.
Intended use.
This power tool is intended for:
commercial use in industry and trade,
screwing in and unscrewing screws and
nuts.
Do not exceed maximum screw/nut
diameter (see “Specifications”).
Only use batteries and battery chargers
from FEIN.
Safety instructions.
Risk of injury
Hold the power tool firmly.
Do not rivet or screw any labels or signs
on the power tool.
We recommend adhesive labels.
Do not use the battery charger, cable, plug
or battery if damaged.
Danger of explosion! Do not throw bat-
teries away in the fire, expose them to
high temperatures or open them.
!
