71
2.6 QoS
The QoS function can classify Internet application traffic by source/destination
IP address and port number. You can assign priority for each type of
application and reserve bandwidth for it. The packets of applications with
higher priority will always go first. Lower priority applications will get bandwidth
after higher priority applications get enough bandwidth. This can let you have a
better experience in using delay-sensitive services like Internet phone, video
conference …etc. All the applications not specified by you are classified as
rule name “Others”. The rule with smaller priority number has higher priority;
the rule with larger priority number has lower priority. You can adjust the
priority of the rules by moving them up or down.
Note: If the total assigned bandwidth of higher priority applications is larger
than the maximum bandwidth provided by the WAN port, then other
applications will not get any bandwidth.
Parameters Description
