37
Click <OK> when you have finished the configuration above. Congratulations!
You have completed the configuration for the PPTP connection. You can start
using the router now, if you wish to use some of the advance features
supported by this router see chapter 2, 3, 4.
1.5 L2TP
Select L2TP if your ISP requires the L2TP protocol to connect you to the
Internet. Your ISP should provide all the information required in this section.
Parameter Description
Obtain an IP
address
The ISP requires you to obtain an IP address by DHCP
automatically before connecting to the L2TP server.
MAC Address
Your ISP may require a particular MAC address to
connect to the Internet. This MAC address is the PC's
MAC address that you originally made your Internet
connection. Type in this MAC address in this section or
use the "Clone MAC Address" button to replace the WAN
