BR-6641 User Manual
51
3.7 Service Grouping
This function allows you to assign a name to a group of TCP ports, UDP ports, and/or
ICMP. Later on when you are asked to specify a port, you can use the name of the
service group instead. The name of a service group will automatically show up in the
port selection list if the service group is enabled.
Figure 3.20 The Location of “System / Service Grouping” on the Menu Bar
Service Grouping:
Field Value Description
Group Name Input the group name, e.g. MSN File
Transfer, then it will appear in the
service menu and relevant options.
Note: You can set at most 5 groups.
Service ICMP
TCP@
Define the assigned TCP, UDP, and
ICMP as a group for the usage in the
