BR-6641 User Manual
10
1.4 How to use BR-6641 Web-based UI
This section describes the operations and arrangement of Web Based UI, figure
1-2 displays the operating menu of BR-6641 Web-based UI system.
BR-6641 Web Based UI Operating Menu Items
1.4.1 BR-6641 Operating Menu
The task bar of operating menu contains five categories, which are System,
Service, Network, Log, each category has these own menu, “System /
Summary” in figure 1-2 indicates the current working menu, while
“Administrator 192.168.2.1” indicates login account is Administrator at system
name of 192.168.2.1.
Select the “Logout” from up right corner to exit the system.
Apply, Reload, Help/Hide Help buttons are always displayed on the operating
menu, the functions are as described below:
Button Function
After modifying the parameters of specific menu
page, click this button to save your changes to
memory, the old settings will also be saved.
