1-5 Familiar with your new wireless network card
EW-7711UAn
1. USB Connector
2. Link/Activity LED
3. WPS Button
4. 3dBi high gain Antenna
LED Name
Light Status
Description
Link/
Activity
On
The network card has linked to a wireless
access point and is receiving or transferring
data.
Off
No wireless activity
2
1
3
4
