Edimax Technology EW-7438RPn User Manual

Page 12

(3) If WPS connection is successfully established, ‘WPS’ LED will light
for 5 minutes; if ‘WPS’ LED flashes fast, there’s something error, please
wait for 2 minutes until ‘WPS’ LED off, and try from step(1) again.

When quick installation is successfully done, ‘Signal” LED will turn on.

(4) Please move repeater to the place you wish to use (a better place will
be the center of your house) and insert this repeater into power outlet on
the wall, the wireless connection will be established automatically.
You can check ‘Signal’ LED status to understand signal reception level.
Steady light: Excellent, Flash: Good, Fast flash: poor.

TIP: If the access point you wish to connect does not have hardware WPS button,

you can also use its web configuration menu’s WPS function to establish

connection. Or you can login this repeater web UI to have quick setup (detailed

setup refers to ‘2-1-2 Web browser quick setup’ manual)

manual)

WPS LED

Signal LED
