13
Chapter 4: Using the Utility Software
4.1 Main Tab
The “Main” tab provides a list of powerline adapters connected to the network. The
upper panel displays local powerline adapters. The lower panel displays remote powerline
adapters in the network.
Connect Click “Connect” and the utility software will scan for other
local powerline adapters.
Rename Select a device and click “Rename” to rename the device.
Enter Password By default, this column is blank. Select a device and click
“Enter Password” to set up a password for the device.
Add This button is used to add a remote powerline adapter to
the existing network.
Scan Click “Scan” and the utility software will perform an
immediate scan of other remote powerline adapters. By
default, the utility automatically scans every few seconds.
