11
1 Intended use
The extraction system is intended for the extraction
of dusts that are non-fl ammable, non-explosive
and not hazardous to health.
The dust extraction system is provided for extract-
ing paint dust.
When handling and extracting fl ammable or explo-
sive dusts or dusts that are hazardous to health,
the safety regulations applicable in your country as
well as the specifi cations of the material manufac-
turer must be observed without fail.
The extraction system must not be operated in
rooms where explosive dust or gas mixtures can
occur.
The extraction system is suitable for continuous
industrial operation.
The user is liable for damage and injury resulting
from incorrect usage!
1.1 Safety instructions
Only use original Festool accessories.
Do not use to extract aggressive liquids (e.g. acids,
alkalis, solvents).
Protect the cable against heat, oil and sharp edges.
The device may only be used by persons who have
been trained in its use and who are authorised to
do so.
Do not operate the machine without a fi lter fi tted
that complies with regulations.
The ventilation and blow-out slits must not be
covered.
2 Installation
For installation of the extraction system and rout-
ing the extraction pipes and outgoing air pipes,
numerous safety regulations and statutory building
requirements are to be observed (e.g. fi re preven-
tion, statics, ventilation and fl uid technics). For this
reason, this work should defi nitely be performed
by a specialist fi rm.
2.1 Setting up
The extraction system must be set up in
such a way that it is protected against
weather infl uences (in particular moisture,
frost, direct sunlight).
Technical data Extraction system TURBO 3091 TURBO 4001 TURBO 7501
Supply voltage (input) V~ 400 400 345 - 415 380 - 480
Line frequency Hz 50 50 50 60
Power consumption W 2200 3000 5500 6300
Compressed air supply max. bar 6 6 6
Volume fl ow (air) max. m 3 /h 266 290 385
Vacuum max. Pa 28000 28000 28000
Sound pressure level in
compliance with EN 60704-1 dB(A) 68 68 74
Filter surface cm 2 50000 50000 50000
Dimensions LxWxH mm 500x1000x900 600x1100x1200
Container capacity l 50 50 80
Weight kg 107 109 200
Dust extraction, connection adapter Ø mm 75 75 75
Protection type IP 54 IP 54 IP 54
External control line V~ 12 12 12
The specifi ed illustrations can be found at the beginning of the operating instructions.
Pictograms
Note, Danger! Manual, read the instructions!
