Part names
Lens ( 
16, 45 66 )
Lens cover ( 
6, 16 66 )
Filter cover ( 
9, 10, 43 00 )
(Air fi lter and intake vent
are inside.)
Elevator button (  12)
Elevator foot (  12)
Remote sensor (  8)
Focus ring ( 
19)
Vent (  10)
AC inlet (  15)
Power switch (  16, 17 66 )
Elevator button (  12)
S-VIDEO port
(  14, 18, 19)
VIDEO port (  14, 18, 19)
CONTROL port (  14)
Part names
Projector
Lamp door ( 
42)
(Lamp unit is inside.)
Elevator foot (  12)
Bottom side
Speaker
Front-Right side
Rear-Left side
Control buttons ( 
5)
Ports
(See below.)
Vent (  10)
Ports
AUDIO port (  14)
Restart switch ( 
17)
RGB port (  14, 18, 19)
Kensington lock slot
