Serial Command Code Table
Function Command Code # Bytes Data Code Meaning
Mouse 05 1 00 Stop mouse function
01-7F Enable mouse function
Communication 06 1 0X 8N1
1X 7N1
X0 1200 bps
X1 2400 bps
X2 4800 bps
X3 9600 bps
X4 19200 bps
Power 11 1 3E Power off
3F Power on
Zoom 12 1 01-3F Zoom +
41-7F Zoom -
Focus 13 1 01-3F Focus +
41-7F Focus -
Mirror 14 1 00 Normal
01 H Invert
02 V Invert
03 H & V Invert
Magnify 15 set Command
1
01 Magnify+
7F Magnify-
Ask Command
1
00 Magnify Off
01 Magnify On
Freeze 16 1 00 Freeze Off (normal display)
01 Freeze On
Input 21 1 11 Video
21 RGB 1
22 RGB 2
Video Type 22 2 00 00 Auto
00 01 NTSC
00 02 PAL
00 03 SECAM
00 04 NTSC 4.43
00 05 M-PAL
00 06 N-PAL
Volume 23 1 00-24 00 - 24 is high end of scale
Mute 24 1 00 Mute off
01 Mute on
Brightness 31 3 00 00 00 - 24 is high end of scale
00 00 24
Contrast 32 3 00 00 00 - 24 is high end of scale
00 00 24
