30 C HAPTER 4: R UNNING THE S ETUP W IZARD
The DSL Mode window allows you to set up the Router for the type of
Internet connection you have. Before setting up your DSL connection
mode, have your account information from your ISP ready.
Select a DSL mode from the following:
■ PPPoE see page 30
■ PPPoA see page 31
■
RFC1483 Bridged see page 32
■
RFC1483 Routed see page 31
and click Next.
For further information on selecting a mode see “Internet Settings” on
page 44 .
PPPoE Mode
Figure 15 PPPoE Screen
To setup the router for use with a PPP over Ethernet (PPPoE) connection,
use the following procedure:
1 Enter your PPP over Ethernet user name in the Username text box.
2 Enter your PPP over Ethernet password in the Password text box.
