H ARDWARE AND S OFTWARE I NSTALLATION
18
13 2 12 3 11 4 10 5 9 6 8 7 15 25 85 30 80 45 75 50 70 55 65 60
RJ-45 cable
(to NIC)
cable outlet
Cable Mode m
PC Link Cable
Status Powe r Status Activity Activity FCN
power supply cable
(to wall outlet)
3Com U.S. Robotics Cable M odem CMX
Installing the Cable Connections CD-ROM
Although you do not need to install the included Cable Connections CD-ROM to use your
Cable Modem CMX, you will want to discover the valuable free software products and Internet
service provider offers included on the CD-ROM. To install Cable Connections, follow the
instructions inside the CD’s jacket or on the CD-ROM itself.
