Multimedia Projector MP8610 9
4-5. Menu Adjustments/Settings
Depending on the current video source selection, the menu items for either the Video Menu or the Data
Menu will display. The table below lists all the menu items that can be adjusted.
An asterisk (*) indicates the item appears on the Data menu only, two asterisks (**) indicate the item
appears on the Video/S-VHS menu only and no marking ( ) indicates the item is common to both menus.
Submenu Menu Item Explanation of Adjustment/Setting
Setup*/Picture** * Selection of graphic mode (e.g. VGA 640 x 480, VESA 800 x
600 72 Hz, etc.). Five user modes. See Appendix C-2.
Brightness Image brightness.
Contrast Image contrast.
V. off.* (vertical offset) Adjusts the vertical position of the image.
H. off.* (horizontal offset) Adjusts the horizontal position of the image.
Color** Color saturation.
Inverse* Inverse image displayed. (Default=off)
Sync* Manual synchronization (phase) or automatic adjustment
using Enter.
Tracking* Manual screen width (total pixel number/line) or automatic
adjustment using Enter.
Pix.* Image format. (For unscaled image use 800 x 600)
Option Projection Change image direction for rear, ceiling mount, rear ceiling
mount and normal projection.
(Default=std.)
Lamp Mode Select lamp power: eco. (low), std. (high) ( Default = eco.)
Remote Turn remote control feature On/Off. (Default=On)
Auto Mode* Turn automatic mode detection On/Off. (Default=On)
Language Select menu display language. (Default=English)
Help Turn menu help text messages On/Off. (Default = On)
Std.** Selection of video standard (Default = Auto)
Lamp* Lamp life indicator. Green bar - lamp is good. Red bar -
lamp needs replacement.
Sog* Sync-On-Green level. Only for Sync-On-Green mode.
Deinterlacing** On = standard video input (VCR)
Off = motion video input (camera)
Reset Restores video modes to factory default settings.
* Change synchronization mode (separate, composite, Sog).
Hue** Color level for NTSC video.
NTSC** Default setting of NTSC image (scaled or unscaled)
Audio Volume Volume level.
Treble Treble setting.
Bass Bass setting.
Balance Left/right balance of speakers.
Audio Speakers On/Off. (Default = On)
Stereo Stereo sound On/Off. (Default = On)
Select audio-in channels (Audio-1/Audio-2) to speakers
according to video selection.
Audio-In 1: Data S-VHS S-VHS
Audio-In 2: Video Data Video
(Default=Data/Video)
Select video source: Data, Video or S-VHS
