Fig.2 engine group – Zenoah STRATO-CHARGED EBZ4800 User Manual
Page 5
1
T1108-12110 CYLINDER
1
2
T1108-12210 GASKET, BASE
1
3
4820-12130 BOLT
4
4
T1108-12310 PLATE
1
5
T4960-50810 SCREW
2
6
T1108-13160 INSULATOR
1
7
8488152000 BOLT
4
8
848GC01431 GASKET, INSU
1
9
T1108-13130 GASKET, CARB
1
10
T1108-15110 MUFFLER
1
13
T4950-67031 BOLT
2
14
T4950-61431 BOLT
1
15
T1108-15210 GASKET, MUFF
1
16
T1108-21101 CRANKCASE-C
1
17
T1108-21140 GASKET, CASE
1
18
T4012-21240 BEARING
2
19
T4019-21210 SEAL
1
20
T1108-21220 SEAL
1
21
04065-03515 SNAPRING
1
22
4820-21310 BOLT
4
23
2750-21211 COVER, MAG
1
24
4820-72150 BOLT
1
25
T1108-41110 PISTON
1
26
2670-41211 RING, PISTON
2
27
2880-41310 PIN
1
28
3350-41320 SNAPRING
2
29
1400-41410 BEARING
1
30
2616-41510 WASHER
2
31
T1108-42000 CRANKSHAFT-C
1
32
1300-42410 SHIM
1
33
1400-43230 NUT
2
34
1000-43240 KEY
1
35
T1108-71110 ROTOR
1
36
T1108-71200 COIL-A
1
37
T1108-72110 • CAP
1
38
T1108-72120 • SPRING
1
39
T1108-72130 • TUBE
1
40
5500-72130 • GROMMET
1
41
4820-72150 BOLT
2
42
T1108-71240 CORD COMP
1
T2070-73110 SPARK PLUG (CHAMPION)
1
**
RZ7C
43
T1108-73110 SPARK PLUG (NGK)
1
**
CMR7H
44
1487-75001 STARTER-A
1
45
1487-75101 • RECOIL-A
1
46
1180-75221 • • SPRING
1
47
1487-75120 • • REEL
1
48
1487-75140 • • DOG
1
49
1861-75150 • • WASHER
1
50
1483-75270 • • SCREW
1
51
1487-75160 • • RETAINER
1
52
1487-75170 • • WASHER
1
Key# PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
53
1400-75160 • • ROPE
1
54
1400-75170 • • KNOB
1
55
1487-75211 • PULLEY
1
56
T4960-51431 SCREW
4
58
T1108-81000 CARBURETOR
1
59
T4950-56240 BOLT
2
60
T1108-82100 BODY-A
1
61
T1108-82130 • PLATE, CHOKE
1
62
T1108-82140 • LEVER
1
63
T1108-82190 • SCREW
1
64
T1108-82180 • O-RING
1
65
T1108-82150 PLATE
1
66
T1108-82300 PACKING-C
1
67
T1108-82310 • PACKING
1
68
T1108-82320 • SCREEN
1
69
T1108-82170 ELEMENT
1
70
T1108-82200 COVER-A
1
71
T1108-82220 • KNOB
2
72
T1108-82061 LABEL, CHOKE
1
73
T4950-64031 BOLT
6
74
6129-61210 BAND
1
75
T4028-75610 LABEL, RECOIL
1
101
T1108-05010 SHORT BLOCK
1
*
Acc
102
T1108-06010 GASKET KIT
1
*
Acc
103
2750-96100 PULLER
1
*
Acc
104
4810-96220 STOPPER
1
*
Acc
105
2750-96230 GUIDE
1
*
Acc
106
2750-96240 GAUGE
1
*
Acc
Key# PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
Fig.2 ENGINE GROUP
(S/N 301604 and up)
EBZ4800
*
Acc: Accessory, which is not included in standard package. **These spark plugs are equivalent.
