Leds and troubleshooting, 1 leds, 1 pla-401/pla401 v2 – ZyXEL Communications PLA470 V2 User Manual
Page 63: Chapter 7 leds and troubleshooting, Table 9 pla-401 lights, Figure 45 pla-401 lights, Leds and troubleshooting (63)
PLA-4xx Series User’s Guide
63
C
H A P T E R
7
LEDs and Troubleshooting
This chapter describes the behavior of the LEDs (lights) and offers some suggestions to solve
problems you might encounter.
7.1 LEDs
The following sections describes the lights on the PLA-400, PLA-400 v2 and PLA402 v2, the
PLA-401, PLA401 v2 and the PLA-470.
7.1.1 PLA-401/PLA401 v2
The following figure is the front panel of the PLA-401. Use the lights to determine if the PLA-
4xx is behaving normally or if there are some problems on your powerline network.
Figure 45 PLA-401 Lights
The following table describes the behavior of the lights on the PLA-401.
Table 9 PLA-401 Lights
LIGHT
ICON
STATUS
DESCRIPTION
POWER
On
The PLA-401 is on and receiving power.
Off
The PLA-401 is not receiving power.
