PANEL LAYOUT
Control Panel
q
w
e
r
t
y
q
INPUT Jack (INPUT)
w
Volume Control (VOLUME)
e
Equalizer Switch (EQ ON/OFF)
r
Equalizer Controls (TREBLE, MIDDLE, BASS)
t
Expansion Output Jack (SLAVE OUT)
y
Power Switch & Lamp (POWER)
BLOCK DIAGRAM
INPUT
3
1
IC1 1/2
IC1 1/2, IC2
BASS
MID TREBLE
EQ OFF-ON
VOLUME
MUTE
TR1, 2, 3
SLAVE
OUT
POWER AMP
SPEAKER
POWER
SWITCH
AC INPUT
POWER SUPPLY CIRCUIT
ACTIVE TYPE
TONE CONTROL
