DS60-112
3
SPECIFICATIONS
Output Power 60 Wrms
Speaker 30 cm x 1 (Celestion SEVENTY 80)
Controller/Switch VOLUME, TREBLE, MIDDLE, BASS, EQ ON/OFF, POWER
Connection Jacks INPUT : Standard Phone Mono Jack
SLAVE OUT : Standard Phone Mono Jack
Input Level/Impedance INPUT : 0 dBm / 100 k
Ω
Output Level/Impedance SLAVE OUT : 0 dBm / 1 k
Ω
Power Requirements U.S. and Canadian models : 120 V, 60 Hz
General model : 230 V, 50 Hz
Power Consumption 70 W
Dimensions (W x H x D) 513 x 491 x 291 mm (20.2” x 19.3” x 101.5”)
Weight 16.0 kg (35 lbs 4 oz)
