Specifications
A–2 975-0288-01-01
Electrical Specifications
Table A-1 Electrical Specifications for the Inverter
Parameter PowerHub 1800 Inverter
Maximum Output Power 1800 W (15A) (5 minutes maximum)
Continuous Output Power 1440 W (12 A)
Surge Rating 2880 W (24 A)
Input Voltage Range 10.5 to 15.0 Vdc
Input Frequency Range 60 Hz
Peak Efficiency 88%
System Shutdown Mode
(Display On) < 12 W
Idle Mode <1.5 W
Output Frequency 60 Hz / ±1 Hz
Output Waveform (resistive load) Modified sine wave (>30% THD)
Output Voltage (at no load) 110 to 125 Vac
Low Battery Cutout 10.5 Vdc with < 240 W load and 11.0 V with > 240 W load
High Battery Cutout 15.0 Vdc
Transfer Relay Rating 20 A
Transfer Time AC to Inverter < 40 ms
AC Qualification Time ~ 20 seconds
Protection • Five 20 A/32 Vdc fuses protecting the 80A/1000 W DC input
terminal.
• Two 20 A/32 Vdc fuses protecting 32A/ 400 W DC input
terminal.
• One 15 Aac supplemental protector.
• One 1 A/250 Vac fuse for system ground fault protection.
Table A-2 Electrical Specifications for the Battery Box
Parameter Battery Box
1
1.Stand-alone battery box Xantrex Part Number: PH1800-BBX
Protection Ten 20 A/32 Vdc Fuses for short circuit and reverse polarity
conditions.
