Parts List
ITEM DESCRIPTION
PART
NUMBER
1 Latch Assembly 105910-052
2 Feed Switch/Sensor Assy (set of 3) 105910-128
3 Upper Cover Support (set of 3) 105910-066
4
Print Head Assy - 4” TLP
Print Head Cable Assy. 105910-053
105910-065
5 Head Up Sensor 105910-129
6 Gap/Blackline Sensor PCBA (set of 3) 105910-054
7 Platen Kit (standard set of 3) 105910-055
8
Front Bezel (standard set of 10)
Front Bezel, Dispenser (single) 105910-057
105910-022
10 Rubber Foot Kit (set of 24) 105910-007
11 Main Control PCBA (RFID) 105910-133
12 Bottom Frame Assy 105910-130
13 Upper Cover Assy 105910-131
14 Ribbon Out Sensor (set of 3) 105910-134
15 Ribbon Carriage w/o printhead 105910-132
Not
Shown
Motor (set of 2)
Power Supply, 100V-240V
Power Cord, U.S. 120V IEC320C13 (set of 5)
PCBA, RFID Reader
PCBA, Antenna, Type 2
Ribbon Core, 4” (set of 50)
Accessory, Media Adapter Plates 105910-051
105950-043
105950-014
105903-135
105950-136
105903-053
810059-001
Manuals
User’s Manual, R402
ZPL II Programmer’s Manual 980389-001
46530L
