Chapter 2
Hardware Installation & Initial Setup
This chapter shows the procedures for installing and operating the Prestige 941 cable modem.
2.1 Front Panel LEDs and Back Panel Ports
2.1.1 Front Panel LEDs
The LEDs on the front panel indicate the operational status of the Prestige 941.
Figure 2-1 Prestige 941 Front Panel
The following table describes the LED functions:
Table 2-1 LED Functions
Function
Naming
Color
LED description
Power
PWR
Green On : Power On
Off :Power Off
System
SYS
Green On: System ready and running OK
Flashing: System rebooting
Off: System not ready
