English

E-45

SPECIFICATIONS

As a part of policy of continuous improvement, YAMAHA reserves the right to make design and specification changes for
product improvement without prior notice. The performance specification figures indicated are nominal values of production
units.

Receiver (RX-S75)

Minimum RMS Output Power per Channel

6 ohms, 1 kHz, 0.08% THD ........................................... 55W+55W
6 ohms, 1 kHz, 10% THD

[U.S.A., Canada, Singapore and General models only]

...................................................................................... 75W+75W

DIN Standard Output Power per Channel [Europe model only]

6 ohms, 1 kHz, 1% THD .......................................................... 60W

IEC Power [Europe model only]

6 ohms, 1 kHz, 0.1% THD ....................................................... 55W

Input Sensitivity/Impedance

PHONO MM [U.K. and Europe models only]

............................................................................ 2.5 mV/47 k-ohms

AUX ................................................................... 390 mV/20 k-ohms

Headphone Output Impedance.......................................... 68 ohms
Total Harmonic Distortion (1 kHz)

AUX to SP OUT (27.5W/6 ohms) ......................................... 0.08%

Signal to Noise Ratio (IHF-A Network)

AUX .........................................................................................90 dB

Tone Control Characteristics

BASS: Boost/cut ................................................... ±10 dB (50 Hz)
TREBLE: Boost/cut ............................................. ±10 dB (20 kHz)

Tuning Range

FM

[U.S.A. and Canada models]...................... 87.5 to 107.9 MHz
[Australia, U.K., Europe, Singapore and General models]
...................................................................... 87.5 to 108.0 MHz

AM (MW)

[U.S.A., Canada and General models] ...... 530 to 1,710 kHz
[Australia, U.K., Europe and Singapore models]

...................................................................... 531 to 1,611 kHz

LW

[U.K. and Europe models only] .................... 153 to 288 kHz

Usable Sensitivity

FM (75 ohms)

(30 dB S/N Quieting, 1 kHz, 100% mod.)

[U.S.A., Canada, Singapore and General models]

.......................................................................1.2

µ

V (12.8 dBf)

(DIN, Mono, S/N 26 dB)

[U.K., Europe and Australia models] ..........................1.5

µ

V

AM (MW)........................................................................ 280 µV/m
LW ................................................................................. 560 µV/m

Power Supply

[U.S.A. and Canada models] ............................ AC 120V, 60 Hz
[Australia model] .............................................. AC 240V, 50 Hz
[U.K., Europe and Singapore models] ............ AC 230V, 50 Hz
[General model] ...................... AC 110/120/220/240V, 60/50 Hz

Power consumption

[U.S.A. and Canada models] ............................................ 155W
[Australia, U.K., Europe and General models] ............... 150W

Dimensions (W x H x D)................................ 280 x 107.5 x 345 mm

(11” x 4-1/4” x 13-9/16”)

Weight .............................................................. 6.0 kg (13 lbs. 3 oz.)

CD player (CDC-S75)

Power Source ................................... AC supplies from receiver unit
Type ................................................. 3 DISC Carousel Auto-changer
Signal Readout

........................... Non-contact, 3-beam semi-conductor laser pick-up

D/A Converter ................................................................... 1-bit DAC
Filter ......................................8-time oversampling 18-bit digital filter
Wow and Flutter .........................................Below measurable limits
Dimensions (W x H x D)................................ 280 x 107.5 x 323 mm

(11” x 4-1/4” x 12-11/16”)

Weight ................................................................ 3.8 kg (8 lbs. 6 oz.)

Tape Deck (KXW-S75)

Power Source ................................... AC supplies from receiver unit
Type ............... Auto Reverse 4-Track 2-Channel playback/recording

and playback stereo double Cassette Deck

Heads ................................................ PB, REC/PB : Hard Permalloy

Erase : Double Gap Ferrite

Motors ................................................................ DC servo motor x 2
Wow and Flutter .................................................

ע

0.19%, W.PEAK

0.09%, W.RMS

Fast Winding Time (C-60 Tape) ........................ About 120 seconds
Frequency Response (–20 dB)

........................................................ 30 – 15,000 Hz

ע

3 dB (Normal)

30 – 16,000 Hz

ע

3 dB (CrO

2

)

30 – 18,000 Hz

ע

3 dB (Metal)

Signal-to-Noise Ratio .................................. 58 dB (Dolby NR OFF)

66 dB (Dolby B NR ON)

74 dB (Dolby C NR ON)

Harmonic Distortion .......................................... No more than 1.2%
Channel Separation (Input Shorted 1 kHz)

................................................................................. More than 40 dB

Crosstalk (Input Shorted 125 Hz).......................... More than 55 dB
Dimensions (W x H x D)................................ 280 x 117.5 x 326 mm

(11” x 4-5/8” x 12-13/16”)

Weight ................................................................ 4.2 kg (9 lbs. 4 oz.)

Speaker (NX-S75)

Type .................................................... Active Servo Processing type
Speakers ........................................................ 14 cm (5-1/2”) woofer

5 cm (2”) tweeter

1.1 cm super tweeter

Frequency Range .................................................... 40 – 20,000 Hz
Sound Pressure Level............................................................. 89 dB
Maximum Power Handling Capacity........................................ 75W
Impedance ............................................................................ 6 ohms
Dimensions (W x H x D)................................... 200 x 330 x 239 mm

(7-7/8” x 13 x 9-7/16”)

Weight ........................................................ 4.5 kg (9 lbs. 14 oz.) x 2
