Fig.1 CUTTER GROUP
Q’TY
Key# PART NUMBER
DESCRIPTION
NOTE
/UNIT
1
848KB05910 FLEX SHAFT ASSY
1
2
848KB05920 • LINER COMP.
1
3
07000-12018 • • O-RING ø17.8X2.4
1
4
3570-21112 • SHAFT-FLEX
1
5
0263-10510 SCREW M5xL10
1
6
8488R40141 LEVER ASSY
1
7
848BC059M0 CLAMP
3
8
848BC03310 • JOINT COMP.
1
9
01252-30520 • • BOLT M5xL20
1
10
T3543-12310 SPACER
1
11
01252-30510 BOLT M5xL10
1
12
T3400-11301 PIPE COMP.
1
13
T3400-12211 SHAFT
1
14
6425-12552 PLATE
1
15
848K9690R1 PLATE
1
16
848K9590U0 LABEL
1
21
T3339-13000 GEARCASE ASSY
1
23
06004-06000 • BEARING
1
24
06000-00626 • BEARING
1
25
04065-02612 • RING
1
26
T3195-13210 • SHAFT
1
27
T3300-93250 • GEAR
1
28
T3002-13260 • NUT
1
29
T3300-93310 • PINION
1
31
3210-13330 • RING
1
32
04065-02412 • RING
1
33
3199-13350 • FITTING
1
34
01641-20608 • WASHER
1
35
0225-00410 • BOLT
1
36
T3300-91340 • HOLDER (A)
1
37
01252-30520 • BOLT
1
38
01252-30512 • BOLT
1
41
T3110-14000 HANDLE ASSY
1
42
0263-90530 • SCREW
4
51
T3189-15102 TAP HEAD COMP.
1
52
T3189-15112 • CASE
1
53
T3189-15191 • EYELET
2
54
T3189-15132 • COVER
1
55
T3189-15142 • CORD HOLDER
1
56
T3189-15160 • SPRING
1
57
T3189-15180 • CORD
1
61
T3338-24120 CLAMP
1
62
01252-30630 BOLT
2
63
848JL066A4 GUARD
1
Q’TY
Key# PART NUMBER
DESCRIPTION
NOTE
/UNIT
64
848JL06634 GUARD ASSY
1
65
848JL066B2 • BLADE
1
66
4820-72150 • BOLT TORX M4xL16 T27
1
67
3238-13150 • NUT
1
71
1030-91340 DRIVER
1
72
3144-91160 SOCKET
1
73
09007-00425 WRENCH
1
74
09007-00528 WRENCH
1
75
3540-91110 BAR
1
76
3540-91120 SPANNER
1
