3
2222 214-72
CONTENTS
Instructions for the User
Important Safety Information 2
Description of the Appliance 4
Operation 5
Before using 5
Starting up 5
Warning light 5
Electronic thermometer 5
Refrigerator compartment 6
Drinks dispenser 6
Superchill compartment 7
Freezer compartment 7
Useful hints for freezing 8
Storing frozen foods 8
Thawing food 8
Ice cube maker 8
Maintenance and Cleaning 9
Periodic cleaning 9
Defrosting 9
Periods of non operation 10
Replacing the bulbs 10
Something Not Working 11
Service and Spare Parts 12
Customer Care 12
Guarantee Conditions 13
Instructions for the
Installer
Technical Specification 14
Installation 15
Positioning 15
Electrical Connection 16
Positioning 17
Height adjustment 17
Fitting the side panels 17
Building the appliance in 18
Fitting the plinth 18
18
Building the appliance in
¥ Fit the appliance into the recess.
¥ Fix it to the wall with the appropriate bracket.
¥ The top of the appliance must be kept clear to
allow correct air circulation. If a wall unit is fitted
above the appliance, there must be a gap of 50
mm between this unit and the wall and it must be
at least 50 mm below the ceiling.
Fitting the plinth
Alignment height of 820 mm
¥ If using a 140 to 170 mm plinth, make a cut-out
as shown.
¥ If using a plinth higher than 100 mm but less than
140 mm, cut the height compensation strip
supplied with the appliance to the required depth
and fit it between the plinth and the ventilation
grille, pressing it into position below this grille.
25
50
50
870
820
140
190 30
100
900
170
220
140
190
