10
OVERALL DIMENSIONS
Width: 860 mm.
Depth: 510 mm.
Height: 72 mm.
Weight: 12 Kg.
CUT OUT DIMENSIONS
Width: 830 mm.
Depth: 480 mm.
Thickness: 30 mm.
Ignition HT Spark
Spark Generator Ispra Control's BF 50066 - 240V 0.6 YA T 120
Spark Gap Fixed
Rear Left Burner (semi rapid)
Heat Input 2.0 kW (6824 BTU/HR)
Front Left Burner (auxiliary)
Heat Input 1.0 kW (3412 BTU/HR)
Burner Dia. Tap By-pass Tap colour
1/100 mm
Auxiliary 28 Green
Semi-rapid 32 Green/Blue
Rapid 40 Green/Black
Ultra-rapid 56 Black/Red
Aeration adjustment none
BURNER RAPID SEMI-RAPID AUXILIARY ULTRA-RAPID
(large) (medium) (small) (double-crown)
POSITION MAX MIN MAX MIN MAX MIN MAX MIN
NOMINAL THERMAL
POWER kW
3.0 0.65 2.0 0.45 1.0 0.33 3.5 1.2
NOMINAL FLOW
RATE m
3 /h 0.286 0.062 0.190 0.043 0.095 0.031 0.333 0.114
NOZZLE REFERENCE 119 Adjust. 96 Adjust. 70 Adjust. 136 Adjust.
NOMINAL THERMAL
POWER kW
2.8 0.65 2.0 0.45 1.0 0.33 3.5 1.2
NOMINAL FLOW
RATE g/h
202 47 144 32 72 24 252 86
NOZZLE REFERENCE 86 40 71 32 50 28 93 56
NATURAL GAS
20 mbar
TYPE OF
GAS
CHARACTERISTICS
LPG GAS
28-30/37 mbar
1/100 mm
1/100 mm VALUE = 49.92 MJ/Kg
VALUE = 37.78 MJ/m
3
Ws - 50.7 MJ/ m
3
Rear Right Burner (semi rapid)
Heat Input 2.0 kW (6824 BTU/HR)
Front Right Burner (rapid)
Heat Input 3.0 kW (10236 BTU/HR)
SUPPLY CONNECTIONS
Gas:
RC 1/2 inch (1/2 inch male) Rear right hand corner
Electric:
230-240V 50Hz supply, 3 core flexible cable with
non rewireable plug fitted with a 3 amp cartridge
fuse.
Central Burner (Ultra-rapid Double-crown)
Heat Input
3.5 kW (11942 BTU/HR)
Instructions for the Installer
Engineer technical data
APPLIANCE CLASS : 3
APPLIANCE
CATEGORY: II2H3+
APPLIANCE
GAS SUPPLY: Natural gas G20 / 20mbar
