Description of the hob – Zanussi GAS HOB ZGF 982 User Manual
Page 4

5
1.
Hob Top
2.
Auxiliary Burner
3.
Semi-rapid Burners
4.
Ultra-rapid Double-crown Burner
5.
Rapid Burner
6.
Ignition pushbutton
7.
Control knob for front left burner (auxiliary)
8.
Control knob for back left burner (semi-rapid)
9.
Control knob for central burner (ultra-rapid)
10. Control knob for back right burner (semi-rapid)
11. Control knob for front right burner (rapid)
1
3
2
4
5
6
7
8
9
3
10
11
Description of the Hob
INSTALLATION
Any gas installation must be carried out by
a registered CORGI installer, and in
accordance with existing rules and
regulations.
The relevant instructions are to be found in the
second section of this manual.
Please, ensure that, once the hob is
installed, it is easily accessible for the
engineer in the event of a breakdown.
WHEN THE HOB IS FIRST INSTALLED
Once the hob has been installed, it is
important to remove any protective
materials, which were put on in the factory.
