Control panel, The oven cavity, Accessories – Zanussi ZCE 610 X User Manual
Page 5: The oven cavity accessories
5
STOP
SET
TIME
PUSH
BOTH
-
+
FRONT LEFT
BACK LEFT
BACK RIGHT
FRONT RIGHT
OVEN FUNCTION
TEMPERATURE
MAINS ON
THERMOSTAT
OVEN PROGRAMMER
1. Oven Thermostat Pilot Light
2. Cooker Operation Pilot Light
3. Front left hotplate control knob
4. Back left hotplate control knob
5. Back right hotplate control knob
6. Front right hotplate control knob
7. Oven function control knob
8. Oven thermostat control knob
9. 24 hour clock and Timer
8
7
6
5
4
2
1
3
Control Panel
The Oven Cavity
Grill element
Oven Light
Accessories
Oven fan
9
Grill trivet
Grill/roasting pan
Removable
handles
