Page 6
Top Panel
Rear Panel
ZOOM
MRT-3
Names
of
Parts
6
Names of Parts
Keys marked (LED) have an integrated LED
that causes the key itself to light up.
Names of top panel controls and rear panel
connectors are indicated with angle
brackets [ ] in this manual.
H
INT
N
OTE
8 8 8 8
Display
[OUTPUT LEVEL] knob
[VALUE +/-] keys
[KIT] key (LED)
[PATTERN] key (LED)
[SONG] key (LED)
[TEMPO] key (LED)
[REC] key (LED)
[PLAY] key (LED)
[STOP] key (LED)
[FUNCTION] key (LED)
[INSERT/COPY] key
[DELETE/ERASE] key
Pads 1 – 7 (LEDs)
[PAD BANK] key (LED)
[DC IN] connector
[OUTPUT MONO] jack
[FOOT SW] jack
[POWER] switch
[OUTPUT STEREO/PHONES] jack
[MIDI IN] connector
