25
valves on the surface burners, insert a small
slotted screwdriver into the hole on the valve
rod and turn the choke screw to the right or
left until the burner flame is adjusted to
minimum.
·
If the cooker is equipped with safety valves,
the choke is not located in the rod hole, but
on the valve body.
· For LPG screw completely the by-pass
screw .
·
Reassemble the parts following the same
procedure in reverse.
Check that, when turning the knob quickly from
the maximum position to the minimum one, the
flame does not go out.
AFTER COMPLETION OF ANY REPAIRS,
ADJUSTMENTS OR CONVERSION THE
STATUTORY SAFETY TESTS MUST BE CARRIED
OUT.
Stick the label supplied with the
appliance (in the nozzles bag) onto the
rating plate in accordance with the gas
type utilised.
The grill burner always operates at maximum and
therefore no minimum adjustment is necessary.
