Specifications of the DR Inverter
975-0012-01-02 Rev A
A–7
Table A-4 Environmental Specifications for the DR Inverter/Charger
a
a.Specifications subject to change without notice.
Model
DR1512
DR2412
DR1524
DR2424
DR3624
Dimensions
b
b.Allows for hardware extensions such as mounting rails, DC terminals, and front panel controls.
8.5" w x 7.25" H x 21" D (21.6 cm W x 18.4 cm H x 54.6 cm D
Unit Weight
35 lbs (16 kg)
45 lbs (21 kg)
35 lbs (16 kg)
40 lbs (16 kg)
45 lbs (21 kg)
“E” Models
38 lbs (18 kg)
N/A
39 lbs (18 kg)
(45 lbs (21 kg)
N/A
Ambient Temp Range (rated 0 to 25 °C):
Operating 0 °C to +50 °C
Storage -55 °C to +75 °C
Altitude:
Operating
15,000 feet
Non-operating
50,000 feet
Mounting
Wall-mount (with 16" mounting centers)
Shelf Mount
