Specifications
A–2 975-0012-01-02 Rev A
Specifications of the DR Inverter
Table A-1 provides the electrical specifications for the DR Inverter/Charger
(120 Vac/60 Hz. models).
Table A-2 provides the electrical specifications for the DR Inverter/Charger
(220 Vac/60 Hz. models).
Table A-3 provides the electrical specifications for the DR Inverter/Charger
(230 Vac/50 Hz. models).
Table A-4 provides the environmental specifications for all models of the DR
Inverter/Charger.
Table A-1 Electrical Specifications for the DR Inverter/Charger
a
- 120 Vac/60 Hz Models
Model DR1512 DR2412 DR1524 DR2424 DR3624
AC Input Voltage 120 Vac 120 Vac 120 Vac 120 Vac 120 Vac
AC Input Low
Transfer Voltage 40-105 Vac 40-105 Vac 40-105 Vac 40-105 Vac 40-105 Vac
AC Input Current
b 45 amps 55 amps 45 amps 55 amps 55 amps
Continuous Power
(@ 25°C) 1500 VA 2400 VA 1500 VA 2400 VA 3600 VA
Continuous Output
(@25 °C) 12.5 amps AC 20 amps AC 12.5 amps AC 20 amps AC 30 amps AC
Efficiency 94% max 94% max 94% max 95% max 95% max
AC Output Voltage
(rms) 120 Vac 120 Vac 120 Vac 120 Vac 120 Vac
Frequency:
(± 0.04% Crystal
controlled) 60 Hz 60 Hz 60 Hz 60 Hz 60 Hz
Surge Capability:
5 sec Rating 2400 watts 4200 watts 3500 watts 6200 watts 7500 watts
1 mSec Rating 38 amps AC 77 amps AC 412 amps AC 80 amps AC 100 amps AC
100 mSec Rating 27 amps AC 55 amps AC 29 amps AC 58 amps AC 72 Amps AC
DC Input Current:
Search Mode 0.045 amps 0.055 amps 0.030 amps 0.030 amps 0.030 amps
Full Voltage 0.700 amps 0.900 amps 0.350 amps 0.450 amps 0.500 amps
DC Current at
Rated Power 165 amps 280 amps 80 amps 140 amps 210 amps
Short Circuit
Current 400 amps 800 amps 280 amps 560 amps 720 amps
