ZyXEL Communications Prestige 630 User Manual
Page 19
Prestige 630 ADSL USB Modem
Installing Your Modem
1-7
1.3.2 Modem Hardware Installation
Step 1. Connect the square end of the USB cable to the back of your modem and then connect the
rectangular end of the USB cable to your computer’s USB port.
Figure 1-12 Back Panel Connections
Connect this cable end to your modem. Connect this cable end to your computer.
Figure 1-13 USB Cable Connectors
Step 2. Use a telephone wire to connect the ADSL port to a telephone wall jack.
Use a splitter (optional) in order to plug a phone into the same telephone line. See the following figure.
