Description of the Appliance
0 1 Top cover
0 2 Programme chart
0 3 Low Temperature Button
0 4 Buzzer Off Button
0 5 Start Button
0 6 Control Lights
0 7 Mains-On Light
0 8 Programme Selector Dial
0 9 Rating Plate
10 Fluff filter
11 Door Handle
12 Adjustable feet
13 Side vent outlet
14 Ring nut
15 Rear vent outlet
11
10
9
1 7 8
2
3
4
5 6
12
DRYING
COOL TUMBLING
END OF PROGRAMME
CLEAN FILTER NOW
FLASHING-DOOR AJAR
START BUZZER
O F F
COTTON LINEN
B C D A STORE DRY IRON DRY STORE DRY EXTRA DRY
SYNTHETICS
L O W
TEMP
T D S 4 8 3 E W A U T O R E V E R S E IMPORTANT: PLEASE READ THE INSTRUCTION BOOK BEFORE USING THIS APPLIANCE
