21
Ref.
No.
Part No. Code Description
1 747-0824 Control Handle Assembly
2 710-1205 Rope Guide
3 720-0279 Handle Knob
4 710-1174 Curved Hd. Bolt 5/16-18 x 2”
6 720-0276 Hand Knob
7 710-0605 Oval C-Sunk Screw
8 736-0501 Spring Washer
9 712-0324 Hex Lock Nut 1/4-20 Thd.
10 746-0876 Throttle Lever
11 749-0438B N Upper Handle
12 720-0295 N Foam Grip
13 749-0907A N Lower Handle
14 726-0240 Cable Tie
15 747-0995 Rear Catcher Frame
16 746-0554
746-0550
746-0737 Control Cable—40”
Control Cable—55”
Control Cable—51”
17 746-0841
746-0842
746-0847 Throttle Control Wire—60”
Throttle Control Wire—51”
Throttle Control Wire—42”
18 747-0995 N Front Catcher Frame
19 664-0084
664-0085
664-0086 Grass Bag Ass’y w/o logo
Grass Bag Ass’y w /logo
Grass Bag Ass’y w/logo
red
20 714-0104 Internal Cotter Pin
21 — Engine
23 782-7599A N Grass Bag Door
24 751B213146
7510007775 Cable Clamp
Cable Clamp†
25 646-0875 Throttle Body
26 811-00500
811-00303
811-00212 Throttle Box Comp.* †
Throttle Box Comp.*
Throttle Box Comp. (Fixed)
29 735-0639 Spark Plug Boot (Optional)
30 732-0700 Wire Rod
31 731-1236 Rear Flap
32 753-0588
748-0376B Blade Adapter Kit
Blade Adapter
33 710-1044 Hex Bolt 3/8-24 x 1.5”
34 736-0524A Blade Bell Support
36 742-0741 Mulching Blade
39 736-0356 Bell Washer .39” I.D. x
1.38”
40 712-0798 Hex Nut 3/8-16 Thd.
41 15261A Height Adj. Plate
42 15262B Pivot Bar
43 732-0404 Spring Lever: Front Wheel
44 738-0507B Shoulder Bolt .5” Dia. x
.357”
45 736-0105 Bell Washer.38” I.D. x .88”
O.D.
47 720-0190 Spring Lever Knob
49 14578
14579
Height Adj. Assembly
Comp.—R.H.
Height Adj. Assembly
Comp.—L.H. (not shown)
50 17488
17489 Pivot Bar—R.H.
Pivot Bar—L.H. (not
shown)
51 782-5002 Front Baffle
53 782-5003 Rear Baffle
54 710-1017 Torx Mach. AB-Tap Scr.
55 710-0549 Hex Screw TT
56 682-3058 N Handle Bracket
Assembly—R.H.
57 682-3059 N Handle Bracket
Assembly—L.H.
58 782-0047-
0691
782-0047-
0606
782-0047-
0650
782-0047-
0662
782-0047-
0667
782-0047-
0483
782-0047-
0629
782-0047-
0638 Deck: Black
Deck: Orange
Deck: Red
Deck: Grey
Deck: Blue
Deck: Charcoal
Deck: Silver
Deck: MTD Red
59 734-1860
734-1864 N Rear Wheel Ass’y. 14”
Rear Wheel Ass’y.
(Models 543, 545I, 549)
60 734-1818
734-1781
734-1841
Front Wheel Ass’y. 8”
Front Wheel Ass’y.
(Models 543, 545I)
Front Wheel Ass’y.
(Models 545, 549)
61 747-0996 N Chute Door Pivot Rod
63 682-7000 Mulching Plug (Hinged)
64 731-1409 Chute Deflector
65 710-0599 Hex Hd. TT Screw 1/4-20 x .5”
66 782-5007 Rear Mulch Plug
67 782-5004 Rear Mulch Baffle
Ref.
No.
Part No. Code Description
* (Includes ref. # 7, 8, 9, 10, & 25)
† Models 543, 545
Table continued on next page
