ZyXEL Communications ZYWALL 100 User Manual
Zywall 100 read me first
ZyWALL 100 Read Me First
Rear Panel Connections
Rear Panel Connections
PORT
CONNECTION
CONSOLE
Connect to your computer’s com port using a console cable.
WAN 10/100M
Connect to a cable/xDSL device using an Ethernet cable.
DIAL BACKUP
Connect to an analog or ISDN device using a console (RS-232)
cable.
POWER
Connect the power cord to the ZyWALL and plug it into an
appropriate power outlet.
TO A COMPUTER
TO A HUB
DMZ
Crossover Ethernet cable
Straight-through Ethernet cable
LAN 10/100M - UPLINK button “on” (pushed in) Straight-through Ethernet cable Crossover Ethernet cable
LAN 10/100M - UPLINK button “off” (out)
Crossover Ethernet cable
Straight-through Ethernet cable
WIRELESS LAN
Use a ZyXEL Wireless PC Card to connect to a wireless LAN.
Register your ZyWALL online at www.zyxel.com for free product updates and information.
