Zoom G2 User Manual
Page 14
Effect Types and Parameters
ZOOM G2
26
EQ
EQ (Equalizer) module
Allows adjusting the three main bands (BASS, MIDDLE, TREBLE) of the six-band equalizer.
BASS
±12 160Hz
MIDDLE
±12 800Hz
TREBLE
±12 3.2kHz
Adjusts the low frequency range level.
Adjusts the mid frequency range level.
Adjusts the high frequency range level.
EXTRA EQ/CABI&MIC
EXTRA EQ/CABINET & MIC module
This module allows adjusting the three remaining bands of the six-band equalizer. In
addition, the module contains a cabinet simulator that produces sound suitable for direct
recording on a MTR or for reproduction via headphones or a studio monitor.
Et EXTRA EQ
Adjusts the three remaining bands of the six-band equalizer. The HARMONICS control allows adjustment of
the harmonics frequency range level.
LO MID
±12 400Hz
PRESENCE
±12 6.4kHz
HARMONICS
±12 12kHz
Adjusts the mid-low frequency range
level.
Adjusts the extremely high frequency
range level.
Adjusts the harmonics frequency range
level.
Cb CABINET & MIC
This effect type simulates amplifier cabinet sound and mic directional characteristics, suitable for direct
recording on a multi-track recorder. The cabinet characteristics are automatically set either to Combo (12" x
1, 12" x 2) or to Stack (12" x 4), depending on the selected drive type. The on/off condition of this effect in
turn automatically switches the modeling algorithm of the DRIVE module (
→
p. 21).
MIC TYPE
dy, Co
MIC POSITION
0 – 2
Selects the mic type. "dy" simulates the
frequency response of a dynamic mic
and "Co" simulates the frequency
response of a condenser mic.
Lets you select different microphone
characteristics according to sound
pickup position. The following settings
are available.
0: Mic pointed at speaker center
1: Mic pointed halfway between speaker
edge and center
2: Mic pointed at speaker edge
MOD/SFX
MOD/SFX(Modulation/SFX) module
Comprises modulation and delay effects such as chorus, pitch shifter, delay, and echo.
CH CHORUS
This effect mixes a variable pitch-shifted component to the original signal, resulting in full-bodied resonating sound.
DEPTH
0 – 98, 1.0
RATE
1 – 50
MIX
0 – 98, 1.0
Adjusts the modulation depth.
Adjusts the modulation rate.
Adjusts the level of the effect sound
mixed to the original sound.
SC STEREO CHORUS
This is a stereo chorus with clear sound.
DEPTH
0 – 98, 1.0
RATE
1 – 50
MIX
0 – 98, 1.0
Adjusts the modulation depth.
Adjusts the modulation rate.
Adjusts the level of the effect
sound mixed to the original
sound.
CH
SC
CB
ET
Effect Types and Parameters
ZOOM G2
27
FL FLANGER
This effect produces a resonating and strongly undulating sound.
DEPTH
0 – 98, 1.0
RATE
0 – 50
RESONANCE
-10 – -1, 0,
1 – 10
Adjusts the modulation depth.
Adjusts the modulation rate.
Adjusts the modulation resonance
intensity.
Pt PITCH SHIFTER
This effect shifts the pitch of the original sound up or down.
SHIFT
-12 – -1, dt,
1 – 12, 24
TONE
0 – 10
MIX
0 – 98, 1.0
Adjusts the pitch shift amount in
semitones. Selecting "dt" gives a
detuning effect.
Adjusts the sound quality.
Adjusts the level of the effect
sound mixed to the original sound.
PP PEDAL PITCH
This effect allows using a pedal to shift the pitch in real time.
COLOR
See Table 1
MODE
UP, dn
TONE
0 – 10
Selects the type pitch change type
effected by the pedal.
Selects the direction of the pitch change.
Adjusts the sound quality.
Table 1
Vb VIBRATO
Effect with automatic vibrato.
DEPTH
0 – 98, 1.0
RATE
0 – 50
MIX
0 – 98, 1.0
Adjusts the modulation depth.
Adjusts the modulation rate.
Adjusts the level of the effect sound
mixed to the original sound.
St STEP
Special effect that changes the sound in a staircase pattern.
DEPTH
0 – 98, 1.0
RATE
0 – 50
RESONANCE
0 – 10
Adjusts the modulation depth.
Adjusts the modulation rate.
Adjusts the modulation resonance
intensity.
dL DELAY
This is a delay with a maximum setting of 2000 ms.
TIME
1 – 99,
1.0 – 2.0
FEEDBACK
0 – 98, 1.0
MIX
0 – 98, 1.0
Adjusts the delay time. In the
range from 10 – 990 ms, the
adjustment is made in 10-ms
steps (1 – 99). For 1 second and
above, the adjustment is made in
100-ms steps (1.0 – 2.0).
Adjusts the feedback amount.
Adjusts the level of the effect
sound mixed to the original
sound.
TAP
Pedal minimum value
Pedal maximum value
Pedal minimum value
Pedal maximum value
UP
dn
UP
dn
UP
dn
UP
dn
1
2
3
4
-100 cent
Original sound only
DOUBLING
Detune + DRY
0 cent
+1 octave
0 cent
-2 octaves
Original sound only
-100 cent
Detune + DRY
DOUBLING
+1 octave
0 cent
-2 octaves
0 cent
COLOR MODE
UP
dn
UP
dn
UP
dn
UP
dn
5
6
7
8
-1 octave + DRY
+1 octave + DRY
-700 cent + DRY
500 cent + DRY
-∞ (0 Hz) + DRY
+1 octave
-∞ (0 Hz) + DRY
+1 octave + DRY
+1 octave + DRY
-1 octave + DRY
500 cent + DRY
-700 cent + DRY
+1 octave
-∞ (0 Hz) + DRY
+1 octave + DRY
-∞ (0 Hz) + DRY
COLOR MODE
TAP
TAP
TAP
PT
FL
PP
VB
ST
DL
