Calibration using
the ILS You can calibrate the EX8002 using the ILS on the digital press.
T O CALIBRATE THE EX8002 USING THE ILS ON THE DIGITAL PRESS
1 Start ColorWise Pro Tools and connect to the EX8002.
For more information about ColorWise Pro Tools and configuring the connection to the
EX8002, see Color Printing.
2 Click Calibrator.
The Calibrator main window appears.
3 In the Select Measurement Method pane, choose ILS.
The ILS Support window appears.
4 Under Available Calibrations, click the calibration set.
The media type, digital press mode, and recommended paper settings associated with the
calibration set appear on the right.
If paper of the correct media type is loaded at the digital press, the paper tray selection is
automatically set to the tray containing the paper.
5 If no paper tray contains the correct media type, you must load the appropriate paper at the
digital press and then select the correct paper tray in the ILS Support window.
6 Click Continue.
The digital press prints and measures the patch pages. When the digital press is done
measuring each patch page, it outputs the page.
7 Click OK to complete the calibration process.
8 Click Exit to close the ILS Support window.
You can view the resulting calibration measurements using Expert mode in Calibrator. For
more information, see Color Printing.
