IDP Support Notes

Servers/PC

192.168.2.5-10

LAN1: 192.168.1.5-50
LAN2: 192.168.1.51-100
WLAN: 192.168.1.101-130
Data Center: 192.168.1.131-140

Device

IDP (A)

IDP (B)

IDP (C)

IP Address 192.168.1.141

192.168.1.142

192.168.1.143

Device

IDP (D)

IDP (E)

IDP (F)

IP Address 192.168.1.144

192.168.1.145

192.168.1.146

Purpose:

IDP (A)

Since network devices may also have vulnerabilities, once the firewall device at gateway is

compromised, the protected networks are also endangered. The IDP device outside firewall can

block attacks to firewall/VPN gateways from Internet. So we apply policy protection on WAN

port of IDP (A).

IDP (B)

Servers in DMZ zone are the most critical point in your network. Since malicious attacks may

flow into DMZ along with legitimate traffic. The attacks may come from Internet and to prevent

the infected server from attacking internal networks, so we apply policy protection on both WAN

and LAN port of IDP (B).

IDP (C), IDP (D)

The purpose of IDP (C) and IDP (D) is to separate internal network into blocks, and thus once a

PC gets infected by some worms/virus, the infection won’t spread into the whole network.

Therefore we apply policy protection on both WAN and LAN port of IDP (C) and IDP (D).

IDP (E)

Since IDP (E) protects the data center of the network, and we assume data center is always

waiting for internal users to access, there are no connections initiated from the data center area.

We apply policy protection on WAN port of IDP (E).

IDP (F)

Wireless LAN is a popular application nowadays due to its mobility. However, WLAN does raise

some security concerns into network applications also because of its mobility. Administrators

can’t predict when a mobile notebook will be cracked, and trying to spread worms/virus through

WLAN. So we suggest users to place an IDP device before WLAN connects to internal network.

The policy protection applies on LAN port of IDP (F).
