York 2000 - Manual (Page 17)

036-21564-003-A-1005
Unitary Products Group 17
ROOF CURB DIMENSIONS
BCH - 3, 4 & 5 TON
COMPRESSOR
AND OUTDOOR COIL
END OF UNIT
DUCT SIZES:
Supply Air = 19" x 19"
Return Air = 19" x 19"
82 1
4
40 3
4
BACK
APPROXIMATE
CENTER OF GRAVITY
44 7
8
FRONT
19 3
4
CENTER OF GRAVITY
CORNER
CORNER
CORNER
OPTIONS / ACCESSORIES
Electric Heat
(Nominal KW)
5 - 7 KW 18
10 - 15 KW 23
20 - 30 KW 28
Economizer 50
Motorized Outdoor Air Damper 26
Barometric Relief/Fixed
Outdoor Air Intake Damper
10
Roof Mounting Curb 92
Belt-Drive Blower 5
BASIC UNIT
BCH
UNIT WEIGHT*
(lbs.)
CORNER WEIGHTS*
(location, lbs.)
“A” “B” “C” “D”
036 628 178 174 137 139
048 668 189 185 146 148
060 693 196 192 151 154
COMPONENT WEIGHTS AND CENTER OF GRAVITY
OUTDOOR COIL
END OF UNIT
CORNER
