M-302 User’s Guide
Chapter 4 ZyXEL Utility Configuration
39
4.3.1 Security Settings
When you configure the M-302 to connect to a network with wireless security activated and
the security settings are disabled on the M-302, the screen varies according to the encryption
method used by the selected network.
4.3.1.1 WEP Encryption
Figure 23 Security Settings: WEP
The following table describes the labels in this screen.
Security
This field shows whether data encryption is activated. If WPA is activated, WPA
displays. If WPA-PSK is activated, WPA-PSK displays. If WEP or 802.11x is
activated, WEP displays. If security is inactive, Disable displays.
MAC Address
This field displays the MAC address of the wireless device.
Surveyed at
This field displays the time when the wireless device is scanned.
Table 7 Site Survey
LABEL
DESCRIPTION
Table 8 Security Settings: WEP
LABEL
DESCRIPTION
WEP
Select 64 Bits, 128 Bits or 152 Bits to activate WEP encryption and then fill in the
related fields.
Authentication
Type
Select authentication type. Choices are Auto Switch, Open and Shared. Refer to
Section 3.2.1.1.2 on page 33
for more information.
Pass Phrase
Enter a passphrase of up to 63 case-sensitive printable characters. As you enter
the passphrase, the M-302 automatically generates four different WEP keys and
displays it in the key field below. Refer to
for more
information.
At the time of writing, you cannot use passphrase to generate 152-bit WEP keys.
Transmit Key
Select a default WEP key to use for data encryption. The key displays in the field
below.
