weber S-470TM - Manual (Page 19)

19
WWW.WEBER.COM ®
19
1
2
3
10
9
8 4
5
7
MANUALLY LIGHTING THE SMOKER BURNER
1) Open the lid.
ƽ DANGER
Failure to open the lid while igniting the grill, or not waiting
5 minutes to allow the gas to clear if the grill does not light,
may result in an explosive flare-up which can cause serious
bodily injury or death.
* The grill illustrated may have
slight differences than the
model purchased.
2) Open smoker box lid
3) Fill smoker with water soaked wood chunks or chips.
4) Make sure that all burner control knobs not being used are turned to “OFF”. (Push
control knob in and turn clockwise to ensure that it is in the “OFF” position.)
5) Turn on the gas at source.
6) Put a match in the match holder and strike the match.
7) Insert match holder and lit match down through cooking grates and Flavorizer ®
bars to ignite smoker burner.
ƽ WARNING: Do not lean over the open grill while lighting.
8) Push smoker burner control knob in and turn to “START/HI”.
9) Check that the burner is lit by looking down through the cooking grate.
ƽ DANGER
If the smoker burner does not light, turn the burner control
knob to “OFF” and wait 5 minutes to let the gas clear before
you try again.
10) Close smoker cover after wood starts to smolder and turn control knob to “LOW”.
TO EXTINGUISH
Push in and turn each burner control knob clockwise to “OFF” position. Turn gas supply
off at the source.
USING THE ROTISSERIE
Note: Before using your rotisserie, measure your food at the widest point. If it exceeds
9½” (241.8mm), it is too large to fit the rotisserie. If it is too large, food can be prepared
using a roast holder and the Indirect Cooking Method.
IMPORTANT SAFEGUARDS
ƽ WARNINGS
•
Read all instructions before using your rotisserie.
• This rotisserie is for outdoor use only.
• Remove motor and store in a dry place when not in use.
• Do not touch hot surfaces. Use barbecue mitts.
• This rotisserie is not for use by children.
• To protect against electrical hazards do not immerse cord,
plugs, or motor in water or other liquids.
• Unplug the motor from outlet when not in use or before
cleaning.
• Do not use rotisserie for other than intended use.
• Make sure motor is off before placing it on the motor
bracket.
• Do not operate the rotisserie motor with a damaged cord or
plug.
• Do not operate the rotisserie motor if it should malfunction.
• The rotisserie motor is equipped with a three prong
(grounding) power cord for your protection against shock
hazard.
• The power cord should be plugged directly into a
properly grounded three prong receptacle. If use of an
extension cord is required, be sure that it is a minimum
16 AWG(1.3mm), 3-wire, well insulated cord marked for
OUTDOOR USE ONLY and properly grounded.
• When using an extension cord, make sure it is not in
contact with a hot or sharp surface.
• Outdoor extension cords should be marked with the letters
“W-A” and a tag stating “Suitable for use with outdoor
appliances”.
• Do not cut or remove the grounding prong from the
rotisserie motor power cord.
• Do not let cord hang over any sharp edge or hot surface.
• To reduce the risk of electric shock, keep extension cord
connection dry and off the ground.
OPERATING INSTRUCTIONS
4 8
