Windsor D250 (115V) - Manual (Page 17)

SOLUTION TANK ASSEMBLY
D-250 98828 06/07/03
16
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 85045 1 VAC MTR ASM, D/B SLTN 115V 2ST
2 39582 1 HOSE, VAC EXHAUST X 9”
3 20046 1 CLAMP, 2.25” WORMGEAR
4 880292 1 WIRE, 4” GRN/14 76010 X 76014
5 87016 1 WASHER, #10 LOCK EXT STAR SS
6 70335 1 SCR, 10-32 X 1/2 PHTR GRN/GRND
7 70813 3 STUD, 1/4-20 X 3.5 SS
8 87013 13 WASHER, 1/4 ID X 5/8 OD SS
9 065-92 3 VAC SPACER 2 1/4 II STAGE
10 35166 1 GASKET, VAC MTR
11 360-24A 1 PLATE ASM, VAC 90 DEG
12A 070-08 1 FAN 105 CFM AXIAL
13 065-91 1 PANEL ASM, CONT. 3 SW W/HEAT
14 070-08A 1 FAN FINGER GUARD
15 70626 4 SCR, #10 X 3/4 PPHST HI-LO BLK
16 70018 1 SCR, 1/4-20 X 1 HHCS SS
17 72142 3 SWITCH, SPST 15A EURO ROCKER
18 060-04A 1 CORD 25’ BLK 14/3 SJTW/A PLUG
19 060-04 1 CORD 25’ BLK 12/3 SJTW/A PLUG
20 170-41 2 LABEL CIRCUIT INTERUPTER
21 170-31 1 HEATER MATE WARNING TAG
22 73195 2 STRAIN RELIEF, 1/2 NPT (.48M)
23 330-06 1 TOGGLE SWITCH BOOT
24 330-05 1 TOGGLE SWITCH
25 3350-04 1 TOGGLE SWITCH PLATE ON/OFF
26A 51116 1 LIGHT ASM, 115V BRUSH WEAR
27 22046 1 CLIP, NEON LAMP
28 500345 1 LABEL, DOM3 SWITCH W/HEAT
29 57040 2 NUT, 1/2 NPT CONDUIT
30 140-11 2 KNOB RT/TANK
31 57105 8 NUT, 1/4-20 HEX W/STAR WASHER
32 87217 1 WASHER, 9/16 ID MCHD
33 030-16 1 ELBOW, 1/4 NPT STREET LONG 90D
34 010-02 1 AXLE ASM, RIGHT
35 151-50C 1 DB 200PSI PUMP TO QD
36 70088 1 SCR, 10-32 X 1/2 PPHMS SS NP
37 20008 1 CLAMP, 5/8 NYLON UL/USA
38 70393 18 SET SCR, 1/4-20 X 1.25L
39 065-26 1 HEATER MOUNT ASM, D/B
40 31017 1 ELBOW, 1/4 FPT X FPT UNION
41 56014 2 NIPPLE, 1/4 CLOSE
42 130-17D 1 HEATER ASM, DB COMPLETE
43 31021 1 ELBOW, 1/4 NPT 45D STREET
44 151-51C 1 DB 200PSI PUMP TO HEATER
45 31016 1 ELBOW, 1/4 NPT STREET
46 20042 2 CLAMP, 3/8 HOSE (D-SLOT)
47 40047 1 HOSEBARB, 1/4NPT X 1/2H 90D DL
48 250-79 1 PUMPTEC 200PSI PUMP & MOTOR
49 66017 2 PLUG, 1/4 BRASS PIPE
50 39174 1 HOSE, 1/2 WIRE BOUND X 23”
51 065-28A 1 PLATE, PUMP MOUNT
52 40027 1 HOSEBARB, 3/8MPT X 1/2 90D DL
53 57187 4 NUT, 6-32 ACORN, ZINC
