Recovery tank assembly – Windsor D250 (115V) User Manual
Page 15
RECOVERY TANK ASSEMBLY
D-250 98828 06/07/03
14
REF
PART NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
05151
1
TUBE ASM, RECOVERY TANK
2
500009
1
LABEL, WARNING
3
260-64A
1
ACCESS COVER CLEAR 6” W/RIM
4
70546
6
SCR, 8 X 3/4 PFHT/S BLK ZINC
5
090-12A
1
FLOAT CAGE ASSY COMPLETE SLIP
6
78475
1
VAC STACK ASM, 17 GAL PORTABLES
7
320-05
2
VELCRO STRAPS
8
15-808123
1
DUMP VALVE 2”
9
11-800444
1
ELBOW, 1.5 2” 45D PVC SCH40
10
390-26
3
SPACER NYLON 1/4 ID X 1/2 OD
11
35168
1
GASKET VAC MTR
12
360-24
1
PLATE, VAC
13
87013
7
WASHER, 1/4 ID X 5/8 OD SS
14
35166
1
GASKET, VAC MTR
15
065-92
3
VAC SPACER 2 1/4 II STAGE
16
85047
1
VAC MTR ASM, D/B RCVRY 115V 2ST
17
70813
1
STUD, 1/4-20 X 3.5 SS
18
87016
3
WASHER, #10 LOCK EXT STAR SS
19
70335
1
SCR, 10-32 X 1/2 PHTR GRN/GRND
20
20063
1
CLAMP, 1.75” WORM GEAR X .312
21
39337
1
HOSE, 1.5 BLK VAC X 24”
22
27508
1
CUFF, VAC HOSE BLU
23
20046
1
CLAMP, 2.25” WORM GEAR
24
880292
1
WIRE, 4” GRN/14 76010 X 76014
25
75334
1
TANK, RECOVERY DB DK GRY
26
70015
2
SCR, 1/4-20 3/4 HHCS SS DL
27
065-25
1
TANK BRACE ASM, D/B
28
70020
2
SCR, 1/4-20 X 1/2 HHCS SS NP
29
40001R
1
HOSEBARB, 1.5 MPT X 1.5
30
39574
1
HOSE ASM, 1/4 HP SLTN 16.5FT
31
150-44A
1
VAC HOSE 16-1/2’ W/CUFFS 1 1/2
32
47356
1
KIT, HOSE ASM W/BAG DOM50
33
150-65
1
HOSE BAG 24” X 36”
34
35255
1
GASKET, TANK LID
35
35256
1
GASKET, DUMP VALVE
36
57105
3
NUT, 1/4-20 HEX W/ STAR WASHER
