Windsor Clipper CLP12IB - Manual (Page 8)

TECHNICAL SPECIFICATIONS
86038280 04/04/07 3-1ENG
ITEM DIMENSION/CAPACITY
Electrical
230-240V, 7A, 50 HZ
Electric Vacuum Motor (1) 3 stage, 1 hp, 99 cfm (2.80 cubic m/min.)
Waterlift 117” (297cm)
Brush (1) 18” (45.7cm.)
Brush Speed 1000 rpm
Solution Pump 100 PSI, diaphragm style, internal bypass
Solution Capacity 12 gallons (45.5l)
Solution Spray 2 quick change jets.
Recovery Capacity 12 gallons (45.5l)
Vacuum Shoe
20” (51 cm) cast aluminum with spring loaded down
pressure
Wheels (2) 10” dia. (25cm) wheels by 2”
Dimensions - Weight 105lbs. (48kg)
Dimensions - Length 28” (71cm)
Dimensions - Height 46” (117cm)
Dimensions - Width 24” (61cm)
Power Cable 50’ (12.7m) (1mm)
28”
(71cm)
46”
(117cm)
24”
(61Cm)
