Windsor Zephyr - Manual (Page 7)

English 7
2.6 Temperature indicator
• This indicator shows you whether you are
working within the proper temperature range
(green area).
2.7 Steam gun
• The steam can be used without accessories for
the following cleaning jobs:
– Deodorizing clothing and removing creases
from garments;
– Dusting houseplants (maintain a distance of
approx. 12 in (30 cm));
– Damp dusting: apply small amount of steam to
surface and then wipe dry with a clean cloth.
2.8 Spot nozzle
•••••
The spot nozzle can be attached either directly to
the steam gun or via the extension tubes.
•••••
Because the steam temperature and pressure
are at their highest immediately the steam leaves
the nozzle, the closer you hold the steam jet to the
object to be cleaned, the better the cleaning
results will be.
•••••
You can use the spot nozzle with its various
attachments for cleaning the following
– areas that are hard to reach, such as corners,
joints, etc.
– venetian blinds, radiators
– toilets and sanitary installations
– stainless steel, windows, mirrors
– taps and fittings
– coated and enameled surfaces
– initial treatment of stains.
•••••
Use the nozzle extension to reach otherwise
inaccessible cracks and joints, etc.
•••••
The power nozzle increases the velocity at which
the steam is discharged from the steam gun. This
makes it particularly suitable for the following, for
example:
– removing particularly stubborn dirt
– blowing steams into corners, cracks,
crevices, etc.
Note:The circular brush is not suitable for cleaning
sensitive surfaces.
2. Directions for use
2.9 Floor nozzle
• Depending upon the actual cleaning task, the floor
nozzle can be used with the extension tubes. You
can use this nozzle for all large washable wall and
floor surfaces. Place the floor nozzle onto the
folded large cloth, and then pull the cloth under
the retaining clips on each side.
• The best results for wiping up dirt are achieved
when you turn the cloth over, or replace it,
frequently.
• For more effective cleaning of heavily soiled
surfaces, slow down your working speed to allow
the steam more time to penetrate the grime.
• Any traces of detergents left on the floor surface
to be cleaned may form streaks. As a rule these
streaks will disappear after the steam cleaner has
been applied several times.
2.10 Hand nozzle
• Depending upon the actual cleaning task, use the
hand nozzle with the extension tubes.
• You can use the hand nozzle with the cloth for
cleaning:
– small washable surfaces
– upholstery
– sensitive surfaces.
2.11 Optional accessories
Only accessories approved by the manufacturer
may be used with this unit.
Household iron (Order no. 6.959-262)
• Connect the modular plug on the household iron
to the main unit.
Steam-ironing
– Rotate the VAPOHYDRO control knob right
round to “–”.
– For ironing all types of fabrics the temperature
control should be set at least to the
...
stage. In
this setting the steam discharged from the iron
prevents the fabric from being overheated.
– The higher the selected temperature, the dryer
and less visible is the steam; the volume of
steam remains the same however.
