030-300224 Rev. A 4
WireSpeed Dual Connect Modem User Guide
5. INSTALLATION INFORMATION
5.1 Installation
Requirements
To install the Westell Dual Connect modem, you will need the following:
1. An Ethernet adapter installed in your PC or a USB adapter installed in your PC.
2. A
DSL-ready line.
5.2 Package Contents
• WireSpeed Dual Connect Modem
• Power Supply
• RJ-45 Ethernet cable (straight-through)
• USB cable
• RJ-11 DSL Phone cable
• Westell CD-ROM containing USB software drivers, optional Diagnostic Icon software
and User Guide in .PDF format
If any items are missing, call Verizon Online DSL Technical Support at the number provided in the “Getting
Started” guide.
5.3 Microfilters
ADSL signals must be blocked from reaching each telephone, answering machine, fax machine, computer modem
or any similar conventional device. Failure to do so may degrade telephone voice quality and ADSL performance.
Install a microfilter if you desire to use the DSL-equipped line jack for telephone, answering machine, fax machine
or other telephone device connections. Microfilter installation requires no tools or telephone rewiring. Just unplug
the telephone device from the baseboard or wall mount and snap in a microfilter, next snap in the telephone device.
5.4 LED Indicators
The LED indicators are used to verify the unit’s operation and status. LED states are described in Table 1.
Table 1. LED States and Descriptions
LED State Description
Solid Green Power ON
POWER
No Light No Power
Slow Flashing Green Power ON and passed power-up diagnostics
(1 flash/sec)
Moderate Flashing Green Power ON and attempting synchronization
(2 flashes/sec)
Steady Green Power ON and synchronized with ADSL line card
Steady Red (less than 20 sec.) Hardware power-up in process
Blinking Red Unit failed power-up diagnostic
Alternating Red/Green Modem diagnostic failed
READY
No Light No Power
Solid Green Ethernet link established
Flashing Green Transmit or Receive Activity ETHERNET
No Light No link established
Solid Green USB link established
Flashing Green Transmit or Receive Activity USB
No Light No USB link established
