MOTOR, BASKET AND TUB PARTS
6
For Model: WTW6400SW2
(White)
W10119754
Illus. Part
No. No. DESCRIPTION
1 W10106600 Cap, Impeller
2 W10076270 Screw & Washer
Assembly
3 W10076260 Washer
4 W10108430 Tub Ring
5
8572540 Hose Pressure
Switch
6 W10076230 Impeller
(Washplate)
7
8533953 Screw,
8−16 x 1.000 (6)
8 W10118114 Hub, Basket−Driven
(Includes Item 9)
9
8545953 Hub, Basket−Driver
(Includes Item 8)
10 W10118182 Basket Assembly
(Includes Items
7, 8, & 9)
11
8572660 Tub & Drive Shaft
Assembly
13
8542674 Weight,
Tub Counterbalance
14 W10004910 Screw,
12−16 x 1−1/4 (2)
15
8557839 Shield,
Drive Motor
(Includes Item 16)
16
8565172 Tube, Buffer
(Set Of 4)
17
8565170 Stator, Motor
(Includes Item 18)
18
8557836 Plate, Stator
(Set Of 2)
19 W10076010 Screw,
1/4−20 x .968 (4)
20
8565188 RPS Assembly
21
8565177 Rotor, Main Drive
Motor (Includes
Item 22)
22
Bolt, Rotor
Assembly
Non−Serviceable
(Supplied W/Rotor)
23 W10058730 Harness, Lower
(Includes Item 5)
24
8566197 Filter, Dual
Pump Hood
25
8533928 Screw,
8−18 x 3/4 (2)
27 W10005430 Clamp, Pressure
Hose Retainer
28
8533957 Screw, 10−16 x 1/2
